Project Description

Standardized modular design
The range of instrument trays consists of 3 sizes, all adapted to fit inside modular wire baskets of the SPRI or ISO standards. This design with modules allows an easy working and full coverage of the instrument set-up of surgical procedures: Additional specialized instrument trays can be combined with a basic instrument tray set-up, thus covering the full requirement of instruments used by each surgery. This also reduces basic instrument requirements and gives more flexible usage. The modular design not only contributes to the utilization of various washer-disinfectors and sterilizers but also by working with the other equipment in the reprocessing flow.
Standardized main goods carrier: STU (DIN), ISO and SPRI – Short description.
Easy to clean and disinfect in a washer-disinfector.
The wire net design allows full inspection and sorting of the instruments contained, contributing to a more efficient reprocessing workflow. It also assure full water coverage of the instruments when in the washer-disinfector, as water can easily penetrate the wire net on the sides of the tray as well. With this design, the utilization of the wash rack is optimal, as trays can be loaded close together, side by side.
Self-drying after disinfection with hot water
The wire design promotes easy drying, as water does not remain on horizontal surfaces. The electrolyte-polished surface adds a second advantage, as water runs off even easier, thus making the tray self-drying after disinfection with hot water (min. +85°C). Circulating air can easily reach every part of the tray and the instruments contained, as sides and bottom are designed as a wire net.
Outstanding precision for safe operation
This range of trays is jig-welded, giving exact dimensions and stability even in case of careless handling.
The tray is designed as a stainless steel wire net, with a maximum square opening of 6.5 mm. The wire diameter is 1.5 mm. This design gives maximum usage for best cleaning results and at the same time prevents instruments from penetrating the sides of the tray.
All cross-points in the network and vertical wires to top and bottom frames are point-welded. All free wire ends are soft-polished to prevent staff injury.
The bottom wire construction includes a rigid, 3 mm diameter, stainless steel wire frame to give airing space between goods and work surface and to allow use on roller, belt and chain conveyors.
Electrolyte-polished for soft and clean surfaces.
Stackable – easy operation
The tray design includes a wire frame at the base that is separated by spacers from the wire net construction itself, making the tray easy to stack and thereby saving space at workplaces. The bottom frame also allows automated transports on various designs of conveyors as it is easy to transfer. Ventilation of the tray and the instruments it contains is promoted with this design, thereby reducing the condensate that arises when a tray is placed on a solid shelf after sterilization.
ITEM STD DESCRIPTION DIMENSION (MM) MATERIAL
8651201107 SPRI INSTRUMENT TRAY, SPRI, MESH 6.5 250 X 170 X 070 SUS 304
8651201108 SPRI INSTRUMENT TRAY, SPRI, MESH 6.5  340 X 250 X 070 SUS 304
8651201109 SPRI INSTRUMENT TRAY, SPRI, MESH 6.5 450 X 340 X 070 SUS 304
8651201110 SPRI INSTRUMENT TRAY LID, SPRI, MESH 6.5  250 X 170 SUS 304
8651201111 SPRI INSTRUMENT TRAY LID, SPRI, MESH 6.5 340 X 250 SUS 304
8651201112 SPRI INSTRUMENT TRAY LID, SPRI, MESH 6.5 450 X 340 SUS 304
8651201113 SPRI TRAY LID WITH HANDLE, SPRI, MESH 6.5 250 X 170 SUS 304
8651201114 SPRI TRAY LID WITH HANDLE, SPRI, MESH 6.5 340 X 250 SUS 304
8651201115 SPRI TRAY LID WITH HANDLE, SPRI, MESH 6.5 450 X 340 SUS 304
